Hard Drive :16 x 3.5-inch SAS/SATA hard drives + 4 x 2.5-inch SAS/SATA hard drives
RAID Controller :RAID 0, 1, 5, 50, 6, or 60
Power Supply :900W/1,500W
PCIe Expansion :10 PCIe 3.0 slots
Network Ports :LOM: 2 x 10 GE + 2 x GE ports
Dimensions :17.5*44.7*74.8cm
Form Factor :4U rack server
MOQ :1 piece
Price :$1,500-2,800 / piece
Contact Now
Product Description
FusionServer 5288 V5 is a 4U, 2-socket rack server, applicable to services such as tiered storage of hot, warm, and cold data,
and historical data archiving. With high efficiency design, the server ensures excellent computing performance and provides
flexible and ultra-large local storage scalability to reduce data storage costs. The 4U server can be configured with 2 Intel®
Xeon® Scalable processors, 24 DDR4 DIMMs , and 44 x 3.5-inch plus 4 x 2.5-inch SAS/SATA disks for local storage, the
FusionServer 5288 V5 supports a maximum of 8 NVMe SSDs. It incorporates patented technologies, such as Dynamic Energy
Management Technology (DEMT) and Fault Diagnosis and Management (FDM), and integrates FusionDirector software for
entire-lifecycle management, helping customers drive down OPEX and improve ROI.
Model
FusionServer 5288 V5
Processors
1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205W
1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205W
Memory
24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel® Optane™ PMem modules (100 series), 2666 MT/s
raid
RAID 0, 1, 5, 50, 6, or 60; optional supercapacitor to protect cache data from power failures; RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration
Hard drive disk
Front:
• 24 x 3.5-inch SAS/SATA hard drives
Embedded:
• 4 x 3.5-inch SAS/SATA hard drives
Rear:
• 16 x 3.5-inch SAS/SATA hard drives
• 16 x 3.5-inch SAS/SATA hard drives + 4 x 2.5-inch SAS/SATA hard drives or NVMe SSDs
• 14 x 3.5-inch SAS/SATA hard drives (or 4 NVMe SSDs for the NVMe model) + 4 x 2.5-inch SAS/SATA hard drives or NVMe SSDs (this configuration does not support internal hard disk and I/O module 1)
Flash storage:
• Two M.2 SSDs
Power supply
2 hot-swappable PSUs with optional 1+1 redundancy. Supported options include:
• 900W AC Platinum PSU
• 1,500W AC Platinum PSU
Network Ports
• LOM: 2 x 10 GE + 2 x GE ports
• Flexible NIC: 2 x GE, 4 x GE, 2 x 10 GE, or 1/2 x 56G FDR IB ports
PCIe Expansion
Up to 10 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC
Form Factor
4U rack server
Dimensions
17.5*44.7*74.8cm
